Make Way For The Manway Cannon!

Posted by Rotating Solutions on Jan 2, 2019 9:41:07 AM

 Untitled design (11)

The Specs:

    • Horizontal angle is a 320 degree rotation
    • Vertical angle is a 155 degree elevation
    • Interchangeable tips from 7/8” to 1-1/4”
    • Hydraulic controlled Umbilical reel
    • LED Explosion proof light
    • Illuminator is 12 degree beam angle up to 300 ft range
    • Effective jet range 115 ft
    • Camera Zoom is 37x
    • 660 GPM @ 200 PSI

Rotating Solutions Service Catalog Rayne LA

The Significance:

  • Horizontal angle is a 320 degree rotation. Can reach more of the tanks surface without constantly moving the cannon which takes a crane or a forklift.
  • Vertical angle is a 155 degree elevation. Able to clean the underside of a floating roof which will reduce the time spent pressure washing. This reduces man power and reduces tank entry which reduces safety risk.
  • Interchangeable tips from 7/8” to 1-1/4”. Gives the user multiple choices of nozzle use. Smaller nozzles reduces diluent use which reduces disposal cost. Larger nozzle with more volume will assist in breaking up hard built up sludges.
  • Accurate movement. – No time delay between the joy stick movement and the movement of the cannon. Better ease for an inexperienced operator.
  • Hydraulic controlled Umbilical reel for ease of removal. Ergonomically advantages and reduces the manpower for rig up and tear down. Reduces time to set up.
  • LED Explosion proof light which is inferred. Using LED vs Halogen reduces the heat of the light and prevents the light cover from building a film on the glass from the heat which can reduce the illumination.
  • Illuminator is 12 degree beam angle up to 300 ft range. Long range view so the operator can visually inspect all of the tank using the camera and light. Don’t have to remove the cannon to inspect or get in tank to inspect cleanliness.
  • Effective jet range 115 ft. Can clean more of the tank without having to relocate the cannon to another manway which can be limited.
  • Camera Zoom is 37x. Can assist in adequately inspecting the tank for cleanliness without having to enter the tank. Can also be used by the tank owner to visually inspect tank floor conditions and shell conditions.
  • Cleaning Medium can be Diesel, Crude Oil, and water. Versatile on the use of cleaning medium. Able to meet the customers requirement for medium use.

Interested in renting this Manway Cannon or equipment?

RSI Rental Solutions

About Rotating Solutions

Rotating Solutions Rayne LARotating Solutions was founded in 2007, and since day one, our vision was to provide a one-stop destination for industrial, refinery, wastewater management, and oilfield solutions, services and rental offerings. Presently, we are a leading provider of equipment and support to industrial refining zones, major operators, independent operators, service companies, rental tool companies, contractors, drilling companies, workover companies, engineering companies, completion companies, and many more.

RSI Rental Solutions, a division of Rotating Solutions Inc., focuses primarily on industrial service rentals for the petrochemical markets, offering superior service while meeting all of your rental needs.

With a focus on 2 & 3 phase centrifuge packages, manway cannons, vacuum systems and diesel pressure washers, we are dedicated to being your one-stop shop, and will work with you and your team to find the solutions that meet your business’s needs, including providing additional equipment.


Topics: Manway Cannons
